  HRB-1112MP HRB-1112 HRB-1212MP HRB-1212
50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz
»ó PHASE 3 3 3 3
¸ðÅÍ
MOTOR		 HP - 16.8 15.0 16.8 - 23.0 20.0 23.0
Kw - 12.6 11.0 12.6 - 17.3 15.0 17.3
ÅäÃâ PRESSURE mmAq - 2500 2500 2500 - 3800 3000 3800
ÈíÀÔ
VACUUM		 mmAq - 2300 2000 2300 - 3000 2300 3000
ÃÖ´ëdz·®
MAX .
AIR FLOW		 §©/min - 18.0 14.0 18.0 - 18.0 14.0 18.0
Àü·ù
CURRENT		 220V A - 45.2 43.3 45.2 - 57.2 52.5 58.4
380V A - 26.1 25.0 26.1 - 33.0 30.8 33.7
¼ÒÀ½
SOUND LEVEL		 dB(A) 80 80 80 80
ÀçÁú MATERIAL IMPELLER Aluminum Aluminum Aluminum Aluminum
CASING Cast Iron Cast Iron Cast Iron Cast Iron
º£¾î¸µ BEARING FRONT 6208ZC3 6208ZC3 6208ZC3 6208ZC3
MIDDLE - - - -
REAR 6308ZC3 6308ZC3 6308ZC3 6308ZC3
¹«°Ô
WEIGHT		 Kg 257 257 280 280
±âµ¿°è±Þ
STARTING CLASS		 H H H H
Àý¿¬°è±Þ
INSULATION CLASS		 F F F F
